SPHC steel coil

SPHC steel coil under JIS G3131 standard, it is a kind of stamping and cold forming steel. JIS G 3131 is a Japanese material standard for hot rolled steel. The commercial quality hot rolled steel is a type of steel that can be used commercially for forming purposes that can also include shearing of a metallic sheet.

SPHC steel coil specification:

Grade: SPHC Standard: JIS G 3131

Thickness: 1.5mm--12.7mm, Width:900mm--1630mm, Length: 3000mm to 15000mm

SPHC steel chemical composition:

Symbol	Chemical composition
Symbol	C max	Mn max	P max	S max
SPHC	0.15	0.60	0.050	0.050

SPHC steel mechanical properties:

Grade	Thickness mm	Elongation (Min %)	Tensile Mpa
SPHC	Thickness mm	Elongation (Min %)	Tensile Mpa
	≤1.6	27	≥270
	1.6-2.0	29
	2.0-2.5	29
	2.5-3.2	29
	3.2-4.0	31
	≥ 4.0	31

SPHC steel coil application:

SPHC steel coil is widely used for parts with common formabilily requirement, such as gear case, electric device, jack shell,collar rim,wheel dish and compressor case.

SPHC steel delivery condition:

AR(As Hot Rolled), N(Normalized), T(Tempered), Q(Quenched), TMCP, Q+T(Quenched and Tempered), UT(Ultrasonic Test: ASTM A435, ASTM A578-C/B/A, EN10160-S0E1, S1E2, S2E3, S3E4), Impact Test, PWHT(Post Weld Heat Treatment), HIC, Z Test(Z15, Z25, Z35).

Bebon International is a professional SPHC steel exporter and a steel stockist in china. Any need in SPHC steel, please feel free to contact us, we will reply you as soon as possible.
