G3+AZ hot rolled aluminum zinc steel is feature for good formability and high reflectivity. G2+AZ hot rolled
aluminum zinc steel is also widely used in hot environment.
Common size for G3+AZ hot aluminum zinc steel
Thickness of G3+AZ hot aluminum zinc steel plate: 0.22 to 1.30mm
Width of G3+AZ hot aluminum zinc steel plate:700 to 1250mm
Length of G3+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of G3+AZ steel strip:508mm
Surface of structural of G3+AZ hot aluminum zinc steel: spangle coating: N, and finishing zinc surface:S
Surface treatment of G3+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U
Chemical composition for G3+AZ aluminum and zinc steel
|
Grade |
C |
Mn |
P |
S |
other alloy element |
|
G3+AZ |
0.08 |
0.40 |
0.030 |
0.02 |
≤0.22 |
Mechanical property of G3+AZ aluminum and zinc steel
|
Grade |
Yield |
Tensile |
Transverse bend test |
Thickness range for lock seam |
|
on 50 mm |
on 80mm |
|||
|
G3+AZ |
34 |
32 |
Flat |
All |
Equal material for G3+AZ aluminum and zinc steel
|
Q/BQB 425-2004 |
AS 1397-2001 |
EN10215-1995 |
ASTMA792M-02 |
JISG3321-1998 |
ISO9364-2001 |
|
DC52D+AZ |
G3+AZ |
DX52D+AZ |
DS |
SGLCD |
2 |
The coating weight of G3+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of G3+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2,
75/75g/m2 , 90/90g/m2
When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.
Application to G3+AZ hot rolled aluminum and zinc plate
1, construction industry
House top, external house, garage door, fence, window-shades
2, household appliance industry:
oven, explosion-proof strip, solar water heaters, electric parts
3,automobile industry
Car muffler, exhaust pipe, signboard
4, industrial instrument
Electric control cabinet, industry refrigeration cabinets, vending machines
Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity
Package for hot aluminum zinc silicon: metal band stapping, out sided diameter ring, making sheet, metal
protective steel sheet, metal steel sheet.
are made under the standard. We can bare any third party to inspect the products, If the product is fake, we can
bare all the losses. Bebon international Co.,ltd prefer the long terms relationship with customer. Please don’t
hesitate to contact us if you require any hot rolled zinc aluminum steel products.
