DC53D+AZ hot aluminum zinc steel

2014/5/4 2:24:41

Common size for DC53D+AZ hot aluminum zinc steel
Thickness of DC53D+AZ  hot aluminum zinc steel plate: 0.22 to 1.30mm
Width of DC53D+AZ hot aluminum zinc steel plate:700 to 1250mm
Length of DC53D+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of DC53D+AZ steel strip:508mm

Surface of structural of DC53D+AZ hot aluminum zinc steel:
spangle coating: N
finishing zinc surface:S

Common surface treatment of DC53D+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U



DC53D+AZ hot aluminum zinc steel


Chemical composition for DC53D+AZaluminum and zinc steel

Grade

C

Mn

P

S

other alloy element

DC53D+AZ

0.08

0.40

0.030

0.02

0.22



Mechanical property of DC53D+AZ aluminum and zinc steel

Grade

steel number

symbol for the
type of hot dip coating

Yield
strength
Mpa(min)

Tensile
strength
Mpa(min)

Min Elongation A80 % min

DX53D

1.0355

AZ

260

380

30



The coating weight of DC53D+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of DC53D+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2

When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.

Application to DC53D+AZ  hot rolled aluminum and zinc plate

1, construction industry
House top, external house, garage door, fence, window-shades
2, household appliance industry:
oven, explosion-proof strip, solar water heaters, electric parts
3,automobile industry
Car muffler, exhaust pipe, signboard
4, industrial instrument
Electric control cabinet, industry refrigeration cabinets, vending machines


Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity

Package for hot aluminum zinc silicon: metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.

Bebon international company can offer all kinds of hot rolled zinc and aluminum steel products. All the material are made under the standard. We can bare any third party to inspect the products, If the product is fake, we can bare all the losses. Bebon international Co.,ltd prefer the long terms relationship with customer. Please don’t hesitate to contact us if you require any  hot rolled zinc aluminum steel products.
