DC53D+Z, DC53D+ZF Hot-dip galvanized steel

2014/4/29 23:28:40

DC53D+Z, DC53D+ZF is the material for hot dipped galvanization under the standard Q/BQB 420-2003. The old grade for DC53D+Z is St05Z, but it is not used now. If need grade St05Z, DC53D+Z can also meet your need.
DC53D+Z, DC53D+ZF Chemical composition:

Grade	Chemical composition %
Grade	C max	Si max	Mn max	P max	S max	Alt min	Ti max	Nb max
DC53D+ Z. DC53D+ZF	0.08	-	0.40	0.030	0.030	-	-	-

DC53D+Z, DC53D+ZF Mechanical Property:

STEEL GRADE	Tensile Strength (MPa)	Yield Strength (Mpa)	n90	r90	Elongation% min (Lo=80mm b=20mm)		The coating adhesion (The heart bending diameter )
STEEL GRADE	Tensile Strength (MPa)	Yield Strength (Mpa)	min	min	<0.7mm	>0.7mm	<140/140	>140/140-175/175	>175/175
DC53D+ Z DC53D+ZF	270-380	140-260	-	-	28	30	0a	1a	2a

a means when the thickness is more than 1.5mm, the minimum value r90 can lower 0.2.
b means when the thickness not more than 0.7mm, the minimum value r90 can lower 0.2, n90 can lower 0.01.
c means For difference thickness of coating products, thick coating surface as the outer surface of the bending test.
