CS type C+AZ Hot aluminum zinc steel

2014/4/30 1:20:11

Common size for CS type C+AZ hot aluminum zinc steel
Thickness of CS type C+AZ  hot aluminum zinc steel plate: 0.22 to 1.30mm
Width of CS type C+AZ hot aluminum zinc steel plate:700 to 1250mm
Length of CS type C+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of CS type C+AZ steel strip:508mm

Surface of structural of CS type C+AZ hot aluminum zinc steel:
spangle coating: N
finishing zinc surface:S

Surface treatment of CS type C+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U



CS type C+AZ aluminum and zinc



Chemical composition for CS type C+AZ aluminum and zinc steel

Grade

C

Mn

P

S

other alloy element

CS type C+AZ

0.1

0.45

0.030

0.02

0.22



Mechanical property of CS type C+AZ aluminum and zinc steel

Grade

Yield
strength
Mpa(max)

Tensile
strength
Mpa(max)

Elongation after fracture
(L0=80mm, b=20mm)%
min thickness(mm)

CS type C+AZ

-

500

22

24



Equal material for CS type C+AZ aluminum and zinc steel

Q/BQB 425-2004

AS 1397-2001

EN10215-1995

ASTMA792M-02

JISG3321-1998

ISO9364-2001

CS type C+AZ

G2+AZ

DX51D+AZ

CS type B type C

SGLCC

1



The coating weight of CS type C+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of CS type C+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2

When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.
Package for hot aluminum zinc silicon:
 metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.


Application to CS type C+AZ  hot rolled aluminum and zinc plate
1, construction industry
House top, external house, garage door, fence, window-shades
2, household appliance industry:
oven, explosion-proof strip, solar water heaters, electric parts
3,automobile industry
Car muffler, exhaust pipe, signboard
4, industrial instrument

Electric control cabinet, industry refrigeration cabinets, vending machines
Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity

Bebon international company can offer all kinds of hot rolled zinc and aluminum steel products. All the material

are made under the standard. We can bare any third party to inspect the products, If the product is fake, we can

bare all the losses. Bebon international Co.,ltd prefer the long terms relationship with customer. Please don’t

hesitate to contact us if you require any  hot rolled zinc aluminum steel products.
