Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity
Common size for S300GD+AZ hot aluminum zinc steel
Thickness of S300GD+AZ hot aluminum zinc steel plate: 0.23 to 1.30mm
Width of S300GD+AZ hot aluminum zinc steel plate:710 to 1250mm
Length of S300GD+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of S300GD+AZ steel strip:508mm
Surface of structural of S300GD+AZ hot aluminum zinc steel:
spangle coating: N
finishing zinc surface:S
Surface treatment of S300GD+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U
Chemical composition for S300GD+AZ aluminum and zinc steel
|
Grade |
C |
Mn |
P |
S |
other alloy element |
|
S300GD+AZ |
0.3 |
1.60 |
0.100 |
0.035 |
≤0.22 |
Mechanical property of S300GD+AZ aluminum and zinc steel
|
Grade |
Yield |
Tensile |
Elongation after fracture (L0=80mm, b=20mm)% min thickness(mm) |
|
S300GD+AZ |
300 |
340 |
18 |
Equal material for S300GD+AZ aluminum and zinc steel
|
Q/BQB 425-2004 |
AS 1397-2001 |
EN10215-1995 |
ASTMA792M-02 |
JISG3321-1998 |
ISO9364-2001 |
|
S300GD+AZ |
G300+AZ |
- |
- |
- |
- |
The coating weight of S300GD+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of S300GD+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2,
90/90g/m2.
Package for hot aluminum zinc silicon:
metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.
1. Car muffler, exhaust pipe, signboard,oven, explosion-proof strip, solar water heaters, electric parts
2, household appliance industry:
3,automobile industry
4, industrial instrument
Electric control cabinet, industry refrigeration cabinets, vending machines
Bebon can offer a competitive price and short delivery time if you plan to purchase 300GD+AZ material. All the material are made
under the standard. We can bare any third party to inspect the products, If the product is fake, we can bare all the losses. Bebon
international Co.,ltd prefer the long terms relationship with customer. Please don’t hesitate to contact us if you require any hot
rolled zinc aluminum steel products. products. All the material are made under the standard. We can bare any third party to inspect
the products, If the product is fake, we can bare all the losses. Bebon international Co.,ltd prefer the long terms relationship with
customer. Please don’t hesitate to contact us if you require any hot rolled zinc aluminum steel products.
