SPCC cold rolled steel

2014/4/29 0:47:53

SPCC cold rolled steel

SPCC is the grade of Japanese standard (JIS) “Cold-reduced carbon steel sheets and strips”
SPCC ,S mean for steel, P mean for plate, C means for cold rolled,C mean for common.

Heat treatment condition: A-annealing  S-annealing +smooth, 8-(1/8) hardness,4-(1/4) hardness, 2-(1/2) hardness 1-hardness.

Tensile ductility level:
ZF-For the most complex parts of coining the drawing
HF-Used to punch the drawing parts is very complex
F-Used to punch the drawing complex parts

For the SPCC steel sheet and steel strip specification lists, the thickness from 0.3-3.5 mm and width from 120-1850mm are all available by our company. For the length, we can offer as your requirements.

SPCC cold plates has Smooth surface, good processing, it mainly used in cars, refrigerators, washing machines and other electrical appliances, and industrial equipment.
The more information of SPCC steel shown in the following table

SPCC Chemical composition

GRADE

C% max

Mn% max

P% max

S% max

SPCC

   0.15

    0.60

  0.100

  0.050


SPCC Mechanical Properties

STEEL GRADE

Tensile Strength

 N/mm (min)

Yield Strength

N/mm (Max)

Elongation min.

      thickness

      >0.25

       >0.25

0.25-0.30

0.3-0.4

0.4-0.6

0.6-1.0

1.0-1.6

1.6-2.5

>2.5

      SPCC

-

-

-

-

-

-

-

-

-


Henan BEBON is the professional Chinese SPCC steel supplier .If you need SPCC , we can put the  order to our steel mill directly or collect these goods from our stock directly if we have enough ex-stock on stock .Besides. if you need any offer or if you want to know the price and any other information about SPCC,please be free to contact us.
