G250AZ hot aluminum zinc steel

2014/4/29 22:39:27

Thickness of G250AZ hot aluminum zinc steel plate: 0.22 to 1.30mm

Width of G250AZ hot aluminum zinc steel plate:700 to 1250mm

Length of G250AZ hot aluminum zinc steel plate:1000 to 6000mm

Inner diameter of G250AZ steel strip:508mm

G250AZ hot aluminum zinc steel

The price of G250AZ is also various from different surface. There are two common surface

condition: spangle coating: N and finishing zinc surface:S.

Surface of structural of G250AZ hot aluminum zinc steel:

spangle coating: N

finishing zinc surface:S

Los acid passivation:C, Smear oil: O, Los acid passivation and oil: CO

Fingerprint resistant membrane: UF, Un-treatment: U

Chemical composition for G250AZ aluminum and zinc steel

Grade	C	Mn	P	S	other alloy element
G250，G1	0.12	0.50	0.040	0.035	≤0.22

Mechanical property of G250AZ aluminum and zinc steel

Grade	Yield strength Mpa(min)	Tensile strength Mpa(min)	Elongation after fracture (L0=80mm, b=20mm)% min thickness(mm)
S250GD+AZ	250	320	12

Equal material for G250AZ aluminum and zinc steel

Q/BQB 425-2004	AS 1397-2001	EN10215-1995	ASTMA792M-02	JISG3321-1998	ISO9364-2001
S250GD+AZ	G250+AZ	S250GD+AZ	255	-	250

Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2

The standard weight of G250AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2,

75/75g/m2 , 90/90g/m2

When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.

Bebon, as one of the most reputable exporter in China, we are professional in C570+AZ. C570+AZ will be made

under the standard. Bebon international CO.,ltd can also offer the professional package with metal band stapping,

out sided diameter ring. Any sizes for this material, you can contact with our company. We will give you the most

professional service.
